DUCT FOR EXTERNAL DISCHARGE LFK (FOR PARTICULATE/GAS FILTER FHC50)

The duct system allows transforming the LFK filter units, equipped with the FHC 50 particulate/gas filter, from reintegration into the environment into extraction units with external discharge. On the top, there is a cover, secured with screws, which also serves as a support for the centrifugal fan. The replacement of the particulate/gas filter is done by unscrewing the screws of the cover.



The duct system consists of:

- 1 discharge duct, made of PVC plastic material, which allows directing the filtered air to a flexible discharge pipe (diam. 100 mm)

- 1 flexible discharge hose, 3 meters long, diameter 125 mm, complete with 2 hose clamps

- 1 discharge terminal for glass mounting with an anti-volatile grid, made of galvanized sheet metal
